Overview
Featured
Overview
| Model | GTBZ56Z |
| Working Height Maximum | 58m |
| Platform Height Maximum | 56m |
| Working radius maximum | 26m |
| Lift capacity(restricted) | 480kg |
| Lift capacity(non-restricted) | 230kg |
| Length( stowed) D | 14.9m |
| Width (axle retracted) | 2.49m |
| Width (axle extended) | 5.1m |
| Height(stowed) C | 3.15m |
| Wheel base F | 5.6m |
| Ground clearance G | 380mm |
| Platform measurement B*A | 2.44*0.91m |
| Turning radius(inside,axle,retracted) | 7.6m |
| Turning radius(inside,axle,extended) | 2.69m |
| Turning radius(outside, axle,retracted) | 10m |
| Turning radius(outside, axle,extended) | 7.07m |
| Travel speed(stowed) | 4.4km/h |
| Travel speed(raised or extended) | 1.1km/h |
| Grade ability-Stowed | 40% |
| Solid tire | 445/65-22.5 |
| Swing speed | 0°~1/3rpm |
| Turn table swing | 360 Continuous |
| Platform leveling | Automatic leveling |
| Platform rotation | ±90° |
| Hydraulic tank volume | 200L |
| Total weight | 27500kg (4WD) |
| Control voltage | 24v |
| Drive &Steering mode | 4*4*4 |
| Engine | Cummins |
| Rated power | Cummins QSB3.9-C100 |
| CONFIGURATION | |
| Engine | Cummins (USA) |
| Variable pump | SAUER (USA) |
| Lifting pump | Cassapa(Italy) |
| Travel motor | SAUER(USA) |
| Travel reducer | PMP(Italy)/Infinity(China) |
| Hydraulic valve | Hydraforce(USA) SANT(China) |
| Swing motor | Wlhionshare(China) |
Featured
Telescopic boom lift
1.Greater lift capacity: The boom is made of high strength steel plate and has sufficient strength and capacity of preventing from flexural deformation. By adoption of modern design tools such as finite element analysis and dynamic simulation, the capacity is greater.
2.Complete safety devices：Standard four-link weighing devices; overload protection, automated detection device for platform amplitudeand height , automatic control of the boom’s movement speed and traveling speed, and weighting with high-precision, to ensure the safety and stability of operation in all directions.
3.Patented socket tow chain mechanism：The tow chain mechanism, which obtains a patent for invention, can prevent the pipes and cables from confusion or fracture due to the deflection & deformation of the boom and the excessive deflection of the cantilever tow chain mechanism, to ensure the reliable operation of the machine.
4. Traveling system :The closed running system consisting of e-proportional variable pump, hydraulic control variable motor and flow distribution valve can gain relatively high movement speed and relatively low and stable running speed. The system works efficiently and generates less heat.
5.Driving Mode 4 × 2/4 × 4 (Optional): The four-wheel drive is powerful with great gradeability; the steering of the four-wheel drive is very flexible and has four steering modes.
7.Hydraulic System: Closed running system, speed easily to be adjusted, wide speed range; the boom’s hydraulic system adopts double valve core circuit, which enhances the safety.
8.Emergency Drop System: It guarantees that the boom can retract and descend in case of failure of the engine and oil pump.
9.Anti-Collision Switch: It is used to prevent the working sidebar from further moving in case of collision with obstacles upward.
